Quick Specs
| Item |
Specification |
| Model |
Huawei S8700-6 |
| Product Type |
Modular Campus Core Switch |
| Slots |
6 Service Slots |
| Switching Capacity |
High-performance backplane architecture |
| Network Layer |
Layer 2 / Layer 3 |
| Uplink Support |
10GE / 25GE / 40GE / 100GE (Depending on Line Card) |
| Redundancy |
Dual Power Supply & Dual Management Modules |
| Application |
Enterprise Campus, Government, Education, Healthcare, Data Center |
| Management |
CLI, SNMP, NETCONF, Web, iMaster NCE |
| Availability |
Brand New / Original / Global Shipping |
Technical Specifications
| Parameter |
Description |
| Product Model |
Huawei S8700-6 |
| Chassis Type |
6-slot Modular Switch |
| Switching Architecture |
Distributed Switching |
| Network Protocols |
IPv4, IPv6, MPLS, VXLAN |
| Layer Features |
Layer 2 & Layer 3 Routing |
| Routing Protocols |
OSPF, IS-IS, RIP, BGP, Static Routing |
| Virtualization |
CSS (Cluster Switch System), VXLAN |
| QoS |
Advanced QoS Policies |
| Security Features |
ACL, DHCP Snooping, IP Source Guard, 802.1X, MAC Authentication |
| Reliability |
Hot-swappable Modules, Redundant Fans, Dual Power Supplies |
| Management Interfaces |
Console, Ethernet Management Port |
| Cooling |
Intelligent Fan Modules |
| Power Supply |
AC/DC (Depending on Configuration) |
| Operating Environment |
Enterprise Indoor Deployment |
| Warranty |
1 Year Warranty |
Huawei S8700-6 Overview
The Huawei S8700-6 is a high-performance modular campus core switch built for next-generation enterprise networks. Designed with a scalable 6-slot chassis, it provides exceptional switching performance, flexible interface expansion, and carrier-class reliability for organizations that require uninterrupted network connectivity.
Supporting advanced Layer 2 and Layer 3 services, the S8700-6 enables enterprises to build highly available campus core, aggregation, and data center networks. Its modular architecture allows businesses to expand network capacity simply by adding service cards, protecting long-term infrastructure investments.
Huawei S8700-6 supports multiple interface types, including 10GE, 25GE, 40GE, and 100GE, making it suitable for modern cloud computing, virtualization, Wi-Fi 6/7 campus deployments, smart campuses, hospitals, universities, manufacturing, and government networks.
With advanced security technologies, intelligent traffic management, VXLAN virtualization, IPv6 support, and comprehensive network management capabilities, the S8700-6 delivers excellent performance while reducing operational complexity.
Whether upgrading an existing enterprise network or deploying a new intelligent campus, the Huawei S8700-6 provides a future-ready, scalable networking solution.
Key Features
- High-performance 6-slot modular chassis
- Flexible expansion with multiple service cards
- Supports 10GE, 25GE, 40GE, and 100GE interfaces
- Enterprise-class Layer 2 and Layer 3 switching
- Distributed forwarding architecture
- Dual management engines for high availability
- Redundant power supplies and fan modules
- IPv4/IPv6 dual-stack support
- VXLAN network virtualization
- Intelligent QoS and traffic optimization
- Advanced security protection
- Easy deployment and centralized management
- Designed for long-term scalability
Typical Applications
- Enterprise Campus Core
- Government Networks
- University Campus Networks
- Healthcare Infrastructure
- Smart Manufacturing
- Financial Institutions
- Large Office Buildings
- Cloud Campus Solutions
- Data Center Aggregation
Why Choose Huawei S8700-6?
✔ Modular design for flexible future expansion
✔ Carrier-grade reliability with redundant hardware
✔ High-density interfaces for growing bandwidth demands
✔ Comprehensive Layer 3 routing capabilities
✔ Lower total cost of ownership (TCO)
✔ Supports cloud-era campus networking
FAQ
Q1: What is the Huawei S8700-6 used for?
The Huawei S8700-6 is primarily deployed as a campus core switch, aggregation switch, or large enterprise backbone switch. It is ideal for organizations requiring scalable, high-performance networking.
Q2: What interfaces does the S8700-6 support?
Depending on the installed line cards, the S8700-6 supports:
This flexibility allows organizations to customize their network according to current and future bandwidth requirements.
Q3: Huawei S8700-6 vs Fixed Configuration Switches
| Huawei S8700-6 |
Fixed Switch |
| Modular chassis |
Fixed ports |
| Expandable interfaces |
Limited scalability |
| Redundant control engines |
Usually single control |
| Higher reliability |
Lower redundancy |
| Suitable for large campuses |
Suitable for branch offices |
If your organization expects network growth, the Huawei S8700-6 offers significantly better scalability and investment protection.
Q4: Does the Huawei S8700-6 support virtualization?
Yes. It supports technologies such as:
- VXLAN
- CSS (Cluster Switch System)
- IPv6
- Network virtualization
- Intelligent traffic engineering
These features make it suitable for cloud campus and modern enterprise deployments.
Q5: Is the Huawei S8700-6 suitable for data centers?
Yes. Although primarily designed for enterprise campus core networks, it is also widely used as an aggregation switch in medium and large data center environments.
